In Pasadena, California, geophysical surveys must address complex alluvial fan deposits and the proximity to active fault systems like the Sierra Madre and Raymond faults. Our category integrates non-invasive methods to map subsurface conditions while adhering to local building codes and ASCE 7-22 standards for seismic site classification. A foundational tool is the GPR survey, ideal for locating utilities, voids, and shallow stratigraphy in urban settings. For deeper shear-wave velocity profiling required by the CBC, we rely on MASW / VS30 testing to determine Site Class directly.
These investigations are critical for mid-rise developments, public infrastructure, and seismic retrofits where undisturbed sampling is challenging. To image deeper bedrock geometry and fault zones, we combine seismic tomography with passive-source techniques. The HVSR microtremor survey provides a rapid ambient-noise alternative for estimating fundamental site period, a key parameter for performance-based design in Pasadena's seismically active corridor.
In weathered granitic soils, passive anchors often outperform active ones because the bond zone develops more reliably against the angular gravel matrix.
Service characteristics in Pasadena California
Live process video
Critical ground factors in Pasadena California
The Raymond Fault runs beneath central Pasadena, and the city sits in Seismic Zone 4 per the 2022 California Building Code. During an earthquake, active anchors can lose prestress if the surrounding soil liquefies or undergoes cyclic softening. We mitigate that by designing sacrificial bond lengths and using corrosion-resistant tendons. Passive anchors, while less sensitive to prestress loss, may experience tension cracks in the grout column if the ground shakes laterally. Our team runs seismic slope stability checks for every anchor wall in this zone.
Our services
We offer four specialized anchor design services tailored to Pasadena's geologic conditions.
Active Anchor Design (Prestressed)
We size prestressed anchors for retaining walls and tiebacks where immediate load transfer is required. Our design includes lock-off load verification and long-term creep monitoring in the Raymond Basin soils.
Passive Anchor Design (Grouted)
For permanent slope stabilization and foundation underpinning, we design fully grouted passive anchors. These systems rely on the bond between the grout column and the surrounding alluvium, with bond lengths calculated from site-specific shear tests.
Anchor Testing and Verification
We perform proof tests, performance tests, and creep tests per ASTM E2398. For active anchors, we verify the lift-off load and elastic elongation. All data is logged and certified by the project engineer.
Corrosion Protection Assessment
Given Pasadena's variable soil chemistry (pH 6.5 to 8.2 in different neighborhoods), we specify double corrosion protection for permanent anchors. We also evaluate stray current risks near existing utilities and metro lines.
Geophysics in Pasadena, California, integrates advanced subsurface imaging with a deep understanding of the region’s complex geology, governed by the building codes and seismic ordinances of Los Angeles County. Our services address the challenges posed by the Raymond Fault zone, alluvial fan deposits from the San Gabriel Mountains, and variable groundwater conditions. This non-invasive discipline maps stratigraphy, detects voids, and locates buried utilities without disturbing the site, which is essential in a city with both historic neighborhoods and dense urban development. By pairing surface methods with direct data from our investigation services and In-Situ programs, we deliver a precise geological model that satisfies the strict requirements of the California Building Code (CBC) and local Pasadena Department of Building & Safety review.
Our methodological framework strictly adheres to ASTM International standards, ensuring data defensibility for any geotechnical or environmental report. We routinely deploy Electrical Resistivity Tomography (ERT) per ASTM D6431, Ground Penetrating Radar (GPR) per ASTM D6432, and Multi-channel Analysis of Surface Waves (MASW) per ASTM D5777 to measure shear-wave velocities for seismic site classification. These techniques are calibrated and directly correlated with mechanical properties through targeted intrusions like the CPT (Cone Penetration Test) and SPT (Standard Penetration Test). This fusion of geophysical and geotechnical data refines the interpretation of soil behavior, eliminating the uncertainty that can arise from relying on a single borehole log in the laterally variable alluvial soils common to the Pasadena basin.
Typical project applications in Pasadena span from foundation design for hillside residences in Annandale to seismic retrofitting of unreinforced masonry structures in Old Pasadena, and large-scale infrastructure along the Arroyo Seco corridor. For shallow foundation assessments, we combine GPR utility mapping with plate load test (PLT) data to validate bearing capacity directly. On larger commercial developments, our MASW surveys map the depth to bedrock and identify velocity contrasts that could amplify ground motion during a seismic event. In environmental site assessments, ERT effectively delineates contaminant plumes or maps the extent of undocumented fill, providing a three-dimensional view that reduces the number of required soil borings and supports a more targeted remediation strategy.
Our geophysical investigation process begins with a desktop study of historic maps and local well logs, followed by field acquisition using calibrated instruments and real-time quality control. The final deliverables include 2D and 3D geophysical profiles integrated with logs from our laboratory testing program, where index properties are confirmed through Atterberg limits and strength parameters are validated by direct shear test results. This comprehensive package provides Pasadena developers, structural engineers, and architects with a clear, actionable subsurface characterization. The core value is risk reduction: by revealing hidden anomalies and accurately modeling site-specific seismic response, we empower our clients to optimize foundation designs, avoid costly construction surprises, and demonstrate full compliance with the stringent local geological hazard ordinances.
